Technical Index:
Laser power: 50W /60W /80W /100W
Laser Type: CO2 Glass-tube laser
Power supply: AC220V +/- 10%/AC110V+/- 10%, 50Hz
Max. Engraving size: 300*200mm (11.81*7.87")
Engraving speed: 0~350mm/s (0~13.8 in./s)
Cutting speed: 0~35mm/s (0~1.38 in./s)
Min. cutting character: Letter: 1x1mm (0.04*0.04")
Operating Temperature: 5~40 degree Celsius
Resolution Ratio: <1000dpi
System Environment: WINDOWS2000/WINDOWS XP/Vista/Win7
Software Supported: MoshiDRAW software (Both NewlyDraw and NewSea fuction)
Type of Cooling: water-cooling and protection system
Graphic Format Supported: BMP/JPG/JPEG/WMF/EMF/PLT
Motor Type: Stepper Motor
Water-break protection: Yes
Gross Weight: 45kgs
Machine Dimension: 750*450*250mm (29.5*17.7*9.8")
Packing: wooden box package
Packing Dimension: 920*600*380mm (36.2*23.6*14.9")
Application:
It is widely used in seal/stamp engraving, electronic, craft and gift, garment, leather, toy, computerized embroidery, packing and printing, shoemaking, furniture, advertising industries ect.
Suitable to rubber, plastic, crystal, Plexiglas, acrylics, bamboo and wooden, marble, granite, ceramtic, glass, china, paper, garment, jade article, glass, shell and other non-metal materials.
